Welcome to our reach based sizing. Remember that at 35% recommended SAG our bikes are longer, lower and slacker than it might look.
SSppeeccssSSppeeccss
SpecsMeet the Elite spec
Our entry range includes reliable and quality specs. Featuring Rockshox suspensions, SRAM GX groupset and DT Swiss 1900 wheels.
Frame
Frame
Unno DASHCarbon fibre monocoque with 140mm of rear travel. Virtual pivot suspension system. Integrated chain guide and seat tube clamp. Downtube protector. EnduroMAX Bearings. Internal cable routing. Boost thru axle 12x148. Post Mount brake system. Max tire width: 2.6”. Oceanworks recycled plastic parts. Recycled rubber protectors. Recommended sag: 35% (+/- 5%).
Headset
Acros Internal Cable RoutingIS52. 1.5 / 1.5, with Acros spider with entry ports for cable routing.
Suspensions
Fork
Rockshox Lyrik Select150mm travel. DebonAir. Boost 15x110mm axle.
Shock
Rockshox Superdeluxe SelectDebonAir. 230x57.5mm.
Transmission
Derailleur
SRAM GX Eagle12 speed. Mechanical. X-Actuation. Colour: Lunar. Cage material: aluminum. Pulley bearings: steel.
Cassette
SRAM GXXG 1275. 500% Range. 10-50. Finish: black. X-Glide 2.
Crankset
SRAM GX EagleAlloy. Lunar. 12 speed.
Chain
SRAM GXEagle technology. 120 links. Solid pin.
Trigger
SRAM GX Eagle12 speed. Mechanical. X-Actuation.
Chainring
SRAM GXDirect Mount, 32T, aluminium.
Wheelset
Wheels
DT Swiss M1900 SplineDiameter: 29". DT 370 hub. 30mm inner width.
Front Tyre
Continental Kryptotal-F Trail29x2.40. Trail endurance. Foldable skin SL. Black/Black.
Rear Tyre
Continental Kryptotal-R Trail29x2.40. Trail endurance. Foldable skin SL. Black/Black.
Brakeset
Brakes
Formula Cura 44x18mm pistons on Caliper. SRAM Mixmaster. Sintered Pads. Axial Master Cylinder. Forged Aluminium. 850mm front hose and 2000mm rear hose.
Discs
Formula Monolitic203mm front and 180mm rear rotors. Thickness: 2.35mm. Extreme lateral stiffness, anti-noise and anti-vibrations design.
Cockpit & seatkit
Dropper
OneUp V2Mechanical. Travel: 120mm for S1, 150mm for S2 and 180mm for S3.
Handlebar
E*Thirteen BaseAlloy. 35mm.
Stem
E*Thirteen BaseAlloy. 35mm.
Saddle
Selle ItaliaSLR Boost.
