Carbon fibre monocoque with 160mm of rear travel. Virtual pivot suspension system. Integrated display, battery, chain guide and seat tube clamp. Motor protector. EnduroMAX Bearings. Internal cable routing. Boost thru axle 12x148. Post Mount brake system. Max tire width: 2.6”. Recommended SAG: 30-35%.
2,52 Kg drive unit with 70Nm (Eco), 105Nm (Auto, Trail, Turbo) and 120Nm (Boost). Offers 250W (rated), 850W (peak) and 1000W (max.) of power.
2-inch OLED smart multi-function touchscreen with 800 nits and 326 ppi.
Wireless Controllers with Bluetooth Connectivity
Integrated 3.74kg battery, delivered with a fast charger, 0 to 100% in 2h 25min.
CANE CREEK 40, No cover, TPR-IS41/28.6/H9 | IS52/40
170mm travel. Kashima coating. Grip X2 damper. Adjustments: HSC, LSC, HSR, LSR. 44mm offset.
230x65mm. Kashima coating. 2-pos lever. VVC Rebound. Adjustments: HSC, LSC, HSR, LSR.
12 speed. AXS Wireless. T-type.
12 speed. Wireless.
XS 1270 T-Type, 10-52t
120 links. Flat top. 12 speed
155mm
Mullet 29" Front and 27.5" Rear.
Ultra Soft, Gravity Pro, TLR, 29” x 2.5”
Soft Evo, Gravity Pro, TLR, 27.5” x 2.5”
4x18mm pistons on Caliper. SRAM Mixmaster. Sintered Pads. Axial Master Cylinder. Forged Aluminium. 850mm front hose and 2000mm rear hose.
203mm front rotor, 200mm rear rotor with integrated speed sensor slots.
ONEUP V2 Alloy handlebar, 35mm diameter, 800mm length, 35mm rise & OneUp 42mm stem.
Mechanical. Travel: 180mm, 31.6mm - 22.2mm
145mm
